Kubernetes Ingress - HTTPS (with ACM + Route53)

Pre-requisite Note
To follow along with the HTTPS demo, you should already have a registered domain name in AWS Route53.
This is important because ACM (AWS Certificate Manager) requires a domain for SSL certificate validation.
For learning purposes, you don’t need to actually implement this step end-to-end. Just understand the flow.

Step-01: What we’ll do

  1. Create ACM cert + Route53 DNS.
  2. Deploy HTTPS Ingress, test end-to-end.
  3. Undeploy the resources after learning

Step-02: SSL Certificate (ACM) + DNS (Route53)

  1. Request Public Certificate in AWS Certificate Manager (ACM):

retailstore.stacksimplify.com
2. Validate via DNS: ACM will show CNAME records to create in Route53 → Hosted Zone: stacksimplify.com. 3. Wait for certificate Status: Issued.

Keep the certificate in the same AWS region as your EKS/ALB.


Step-03: Kubernetes Manifests (Ingress - HTTPS)

Folder: https_retail_store_k8s_manifests/

Update both Ingress Manifests with SSL Certificate ARN

    ## SSL Settings
    alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:us-east-1:180789647333:certificate/af739d1d-c527-4a44-a753-464f775dca25

K8s Ingress HTTP Flow

Deploy Kubernetes Ingress HTTPS

# Apply all HTTPS manifests (includes Ingress with TLS annotations)
kubectl apply -R -f https_retail_store_k8s_manifests/

Create DNS record (Route53)

After ALB is provisioned (check ADDRESS column):

kubectl get ingress

In Route53 → stacksimplify.com, create CNAME:

Name: retailstore.stacksimplify.com
Type: CNAME
Value: <ALB-DNS-NAME>
TTL: 60

Step-04: Verify Kubernetes Ingress - HTTPS

# Ingress overall
kubectl get ingress -A

# Inspect annotations, rules, and TLS
kubectl describe ingress retail-store-https-instance-mode
kubectl describe ingress retail-store-https-ip-mode

# Test HTTPS with SNI
curl -vk https://retailstore.stacksimplify.com

Expect a valid TLS handshake (issued by ACM) and Retail Store UI over HTTPS.


Step-05: Undeploy Ingress HTTPS

kubectl delete -R -f https_retail_store_k8s_manifests
